| Lieu d'origine: | Fujian, Chine |
|---|---|
| Nom de marque: | HI-CREATE |
| Certification: | CE |
| Quantité de commande min: | 1 ensemble |
| Prix: | $13,000.00 - $19,900.00 / Set |
| Détails d'emballage: | Le tissu non tissé jetable de visage de pliage faisant l'équipement emballe par la caisse de contrep |
| Délai de livraison: | 60 jours |
| Conditions de paiement: | L/C, T/T |
| Capacité d'approvisionnement: | 1 ensemble par mois |
| Industries applicables: | Usine | condition: | nouveau |
|---|---|---|---|
| Type de produit: | Tissu facial | Traitement du type: | Machine se pliante de papier |
| Tension: | 380V ou 220v | Puissance (w): | 4KW |
| Dimension (l*w*h): | 4.1*1.7*2.1 m | Poids: | 2600 kilogrammes |
| Capacité de production: | 3200 feuilles/minute | Modèle (HC-L-NW): | 4L |
| Largeur de papier crue maximum de petit pain: | 840mm | Matériel de papier cru: | 15-40g/m2*1layer |
| Diamètre de papier cru maximum de petit pain.: | Norme 1100mm ou ≤1200mm | Diamètre de papier cru de noyau de petit pain.: | 3' (76.2mm) |
| Les produits finis ont ouvert la taille: | (140, 150, 160-210) * (140-210) (millimètre) | Les produits finis ont plié la taille: | (70-105) * (140-210) (millimètre) |
| vitesse de machine: | 60-100m/min | Contrôleur de programme: | Contrôle de PLC, écran tactile |
| Système pneumatique: | Compresseur de l'air 3HP, mini PA de la pression 5kg/cm2 | Service après-vente fourni: | Support technique visuel, installation de champ, commissionnant et s'exerçant, appui en ligne |
| Garantie: | 12 mois | Port: | Xiamen |
| Surligner: | 3200 Sheets/Min Facial Tissue Machine,840mm Facial Tissue Making Machine,4L Facial Tissue Making Machine |
||
The working principle of Disposable folding non woven face tissue making equipment is as follows: simultaneous unwinding of two rolls - embossing - cutting - adsorption - helical knife roll shearing - mutual buckle folding - left and right swing counting - finished product output.The equipment adopts automatic feeding device, pneumatic control, saving time and labor.The device is a rectangular tissue paper which is cut by spiral knife roller and folded into chain by mutual button. The device adopts vacuum adsorption automatic cutting counting function, which has the advantages of high speed, neat folding and simple operation.The equipment adopts PLC programming control system, computer touch screen display, frequency conversion and joint control.
1.Folding type: V type folding,paper in upper and lower position are jointed and folded with auto counting unit and output in stack, folding with vacuum adsorption.
2.Paper is conducted by spiral cutting by sections with convenient adjustment in cutting tool.
3.Slitting width can be adjustable while products are in trim.
4.Unwinding of jumbo roll is pushed an fed by the flat belt ,equipped with step-less speed regulator to adjust tension of unwinding.
5.Adopt PLC and frequency speed regulator control.
Packing & Shipping:
Our Company & Factory:
HI-CREATE is manufacturer for disposable hygiene products machinery development, design and producing, mainly in production line for baby diaper , sanitary napkin, waistband diaper , training pant(pull up) diaper, adult diaper , and a series of household paper, disposable products processing equipment for toilet paper, tissue paper, and napkin paper.
Our Office:
Our Services:
Our Visitors:
Our Certificates:
Our Exhibition:
Customer Message:
Customer’s Photos:
FAQ:
1. Are you a manufacturer or trading company?
We are a manufacturer with our factories, more than 10-year experience in this industry.
2. Where is your factory?
Our factory locates in Xidong Industrial Zone, Huian Town, Quanzhou, Fujian, China.
3. How long is the turnaround time?
It takes about 30-60 working days to finish. And it depends on different products and customized requirements.
4. How long is your delivery time?
15-60 days after order being confirmed. Detailed delivery date should be decided according to production season and order quantity.
5. Can your machine do customization for our products?
We could do some customization size to fit your products size according to your requirement.
